Product details
Introducing our premium quality speaker wire, designed to deliver exceptional performance and reliability. This 14AWG, 2C wire has been specifically engineered for direct burial, ensuring that it can withstand the toughest outdoor environments. The OFC shielded construction offers superior protection against interference and noise, ensuring that you get a crystal-clear audio signal every time. With a massive 500 ft. length, this wire is perfect for long-distance installations and larger projects. So whether you’re setting up a home theater system or installing outdoor speakers, our speaker wire is the perfect choice for the job. Buy now and experience the difference in sound quality!
Product Specs
| Manufacturer Part # | 14/2SHDB-500 |
| Marking | STRUCTURED CABLE PRODUCTS – – – P/N 14/2SH-DB – – – 2 COND 14 AWG STRANDED SHIELDED PE JKT CMX OUTDOOR / DIRECT BURIAL — CE EU RoHS EC ZONE/DEVICE A B C D E 0 1 3 4 5 6 7 8 9 XXXXFT |
| Regulatory | UL 444, UL 13, NEC Article 760, NEC Article 725 EU RoHS 2011/65/EU Compliant |
| Application | Speaker Cable |
| Construction Characteristics | Conductor Material: Stranded Bare Copper Size: 14AWG X 2C (2.11mm²) Construction: 105/0.16mm (0.0063 inch) ±0.004mm Insulation Material: PVC Min. Thickness: 0.33mm (0.0130 inch) Avg. Thickness: 0.36mm (0.0142 inch) Diameter: 2.60mm (0.1024″) ±0.05mm Colors: Black and Red Shield Core Wrap: PE Tape Drain Wire: 7/0.20mm (0.0008 inch) ±0.004mm Shield: AL Foil Filler: Waterproof Jacket Material: LLDPE Min. Thickness: 0.60mm (0.0236 inch) Avg. Thickness: 0.54mm (0.0213 inch) Diameter: 7.20mm (0.2835 inch) ±0.10mm Color: Black |
| Electrical & Physical Characteristics | Rating: 75°C 300V Conductor Resistance: Max 9.2ohm/km at 20°C Insulation Resistance: Min 50M ohm·km at 20°C Dielectric Strength: Min AC1.5KV AC Leakage Current Through Overall Jacket: AC 1500V Twists Per Foot: 2.5 Cold Bend Test: -20°C 4 hours; No Cracking Insulation Unaged: Tensile Strength: 13.8Mpa Elongation: 150 percent Insulation Aged: Tensile Strength: 11.7Mpa (100°C 168h) Elongation: 80 percent (100°C 168h) Jacket Unaged: Tensile Strength: 10.8Mpa Elongation: 300 percent Jacket Aged: Tensile Strength: 9.2Mpa (100°C 168h) Elongation: 150 percent (100°C 168h) |
