| Manufacturer Part #: |
5280C |
| UPC: |
8436031618808 |
| Outputs: |
Stereo Line Right Speaker Left Speaker Amplifier Trigger |
| Speaker Impedance: |
4/8/16 ohms |
| Speaker Output: |
5W stereo max. |
| Speaker Color: |
White |
| Other Connection: |
Volume limitation and mono/stereo jumpers |
| LED Display: |
Off: Disconnected and Audio Off |
| Bluetooth: |
Blue Flashing – searching BT Device |
| Bluetooth: |
Blue On – BT connected |
| Audio-In: |
Red On – Audio-In Activated |
| Voltage Terminals VDC, GND: |
Normal: 15Vdc Max: 16Vdc |
| Consumption Demand Bluetooth: |
Minimum: 22mA Normal: 111Vdc |
| Consumption Demand Jack 3.5mm: |
Minimum: 22mA Normal: 99Vdc |
| Input Signal Jack 3.5mm: |
Normal: 100mVrms Maximum: 550mVrms |
| Input Signal Jack 3.5mm Input Impedance: |
Minimum: 7Kohms Maximum: 60Kohms |
| Output Signal Output 4 ohm: |
Maximum: 5Wrms |
| Output Signal Output 8 ohm: |
Maximum: 2.5Wrms |
| Output Signal Output 16 ohm: |
Maximum: 1.5Wrms |
| Line Output Signal Terminals 65, 66, 4: |
Maximum: 1.82Vrms |
| Line Output Signal Terminals 65, 66, 4 Output Impedance: |
Maximum: 50ohm |
| Amplifier Trigger Signal Terminals 62, 4: |
Maximum: 14Vdc |
| Amplifier Trigger Signal Terminals 62, 4 Output Impedance: |
Maximum: 1Kohms |
| Left/Right Channel Separation: |
Normal: 58dB Passband: Minimum: 45Hz Maximum: 20000Hz |
| Distortion: |
Normal: 0.1% |
| SNR: |
Normal: 84dB |
| Bluetooth Identification Number: |
Minimum: 0000 Maximum: 9999 |
| Bluetooth: |
Class2 BT2.1 + EDR A2DP 1.2 AVRCP 1.4 |
| Wireless Transceiver: |
2.4GHz RF Power Transmitter: 7 dBm |
| Dimensions: |
Exterior: 1.8 x 1.8 x 1.7 inches (45 x 45 x 42mm)
Cavity: 1.8 x 1.8 x 1.4 inches (45 x 45 x 36mm)
Face Cover: 1.8 x 1.8 inches (45 x 45mm) |
| Range: |
33 feet (10m) |
| Warranty: |
2-Year |
